ClearView
Minimal Aluminium Sliding System
Simplicity in it’s Purest Form.
Get the best panoramic view with ClearView® minimal aluminium sliding system.
The width of the room takes a whole new dimension with the interiors merging with the outdoors. With the ability to create large glazed areas, allowing maximum brightness and transparency to your living, ClearView® minimal aluminium sliding system is the perfect solution for maximizing space and minimizing the barriers between the inside and the outdoors.
With ClearView®, you can even integrate Venetian blinds in the glass panels avoiding hassles of installing large curtain which is difficult to maintain and operate.
FEATURES
- Vertical track along with handle section is 80 mm (face width).
- Interlock face width is only 20 mm.
- Top & bottom track 53 mm (face width).
- Maximum shutter size = Maximum glass panel available in the market.
- Windload upto 3.6 kPa.
- Maximum load per shutter upto 700 Kgs.
- Provision for glass panels from 8 mm to 50 mm.
- Multi-point locking.
- Reverse interlock available (center opening with multi-point locking).
- Minimal effort & smooth operation for large shutters.
- Option of floating 90° corner shutters available.
- Any number of tracks possible thanks to thermal-break design.
- Energy saving & excellent noise insulation.
- Made for indian conditions.
- Shutter top and bottom is hidden inside the track. Hence, the only true minimal system available in the Indian market.
